封装

Toshiba Package Name	SO16L
Package Image
Pins	16
Mounting	Surface Mount
Width×Length×Height (mm)	10.3×10.0×2.1
Package Dimensions	查看
Land pattern dimensions	查看
Ultra Librarian^® CAD model (Symbol, Footprint and 3D model)	Download from UltraLibrarian^® in your desired CAD format 1 3
SamacSys CAD model (Symbol, Footprint and 3D model)	Download from SamacSys 2 3

Please refer to the link destination to check the detailed size.

*1	Ultra Librarian^® is a Registered trademark and CAD model library of EMA (EMA Design Automation, Inc.). CAD models (Symbol/Footprint /3D model) are provided by UltraLibrarian^®. The footprints are generated based on the specifications of Ultra Librarian^®.
*2	SamacSys is a wholly owned subsidiary of Supplyframe, Inc. CAD models (Symbol/Footprint /3D model) are provided by Supplyframe, Inc. The footprints are generated based on the specifications of SamacSys.
*3	Please note that the footprint dimensions may differ from the reference Land Pattern dimensions provided on our website.

绝对最大额定值

项目	符号	值	单位
Supply Voltage	V_CC	-0.5 to 35	V
Operating Temperature	T_opr	-40 to 110	℃

电气特性

项目	符号	条件	值	单位
Pulse width distortion	\|tpHL-tpLH\|	-	50	ns
Isolation voltage	BV_S	t=60sec	5000	Vrms
Common mode transient immunity	CM_H / CM_L	-	+/-35	kV/μs
I_CC (Max)	I_CC	-	3.8	mA
threshold input current(L/H)	I_FLH	-	6	mA
Output Current Iout (peak) (Max)	I_OP	-	+/-4.0	A
Propagation delay time (H/L)(Max)	tpHL	-	150	ns
Propagation delay time (L/H)(Max)	tpLH	-	150	ns
Supply Voltage(under Recommended Operating Conditions)(Max)	V_CC	-	30	V
Supply Voltage(under Recommended Operating Conditions)(Min)	V_CC	-	15	V

Notes

The Part Number column shows representative part numbers only, which may not be available for sale in the precise form shown. Each Part Number constitutes a product family which may contain multiple associated product configurations.
(#) Under the RoHS Compatible Product(s) column, "Available" means at least one RoHS-Compatible product is available for sale in the corresponding product family. "None" means no RoHS Compatible product is available in that product family. For Toshiba's definitions of concepts related to the RoHS Directive and RoHS Compatibility, please click here.
The RoHS compatibility information provided herein is to the best of Toshiba's knowledge and belief accurate as of the date Toshiba entered the information into this database. Information is subject to change at any time without notice.
Please contact your Toshiba sales representative for detailed environmental information about each specific part number or product, such as RoHS compatibility or material content. Please use Toshiba products only in compliance with all applicable laws and regulations concerning the inclusion or use of controlled substances, including without limitation the RoHS Directive.TOSHIBA ASSUMES NO LIABILITY FOR DAMAGES OR LOSSES OCCURRING AS A RESULT OF NONCOMPLIANCE WITH APPLICABLE LAWS AND REGULATIONS.
Reliability data are provided for your reference only, please contact your Toshiba sales representative for detailed reliability information about each part number.
For product delivery, additional characters will be added to the part numbers shown on this website. For details, please ask your local distributor, or send an inquiry accessed from "Contact Us" on this website.

Feature	2.3mm low-profile package / Creepage and clearance 8mm / High temperature 110 degC operation
Application Scope	Factory automation / Inverter / PV inverter
Function	IGBT driver
Number of Circuits	1
Output Interface	totem-pole(BUF)
RoHS Compatible Product(s) (#)	Available
Safety Standard	Approved　:　UL 1577 / cUL (CSA Component Acceptance Service No. 5A) / EN 60747-5-5 (VDE) / EN IEC 62368-1 (VDE) / GB 4943.1-2022 (CQC) 1 Download Online Certification of Safety Standard(UL 1577) 2 Download Online Certification of Safety Standard(cUL)

Orderable part number (example)	MOQ(pcs)	Reliability Information	RoHS	库存查询
TLP5214A(D4-TP,E	1500		Yes
TLP5214A(TP,E	1500		Yes
